Application range of simple beam impact testing machine:

Charpy impact testing machine is mainly used for hard plastic, reinforced nylon, glass steel, ceramics, cast stone, determination of non-metallic materials, impact toughness of electrical insulating materials etc.. The testing machine is an ideal test equipment for chemical industry, scientific research institutes, colleges and universities, quality inspection departments, professional manufacturers laboratories and other units. Chinese character LCD screen display results, can store multiple sets of test results, and has the energy loss of automatic correction function. The pendulum impact testing machine is simple in structure, convenient in operation and accurate in data.

Simply supported beam impact testing machine:

Meet the requirements of GB/T 13525 and ISO 8256 standards.

KXJJ series of electron beam impact testing machine

KXJJ series of electronic beam impact testing machine technical parameters:

1) measurement accuracy: 0.1% resolution: 1%

2) impact speed: 3.8m/s

3) the lifting angle of the pendulum hammer: 150

(4) the corner radius of the impact edge: (2 0.5) mm

5) impact swing moment: pd15=8.03848Nm pd7.5=4.01924Nm

Pd50=26.79492 Nm pd25=13.39746Nm

6) strike center distance: 395mm

(7) the angle of impact cutting edge: (30 1) o

8) jaw fillet radius: (1 0.1) mm

9) the distance between the jaw support line: 62mm

10) power supply: 220VAC 50HZ 100VA

11) size: length 550mm * width 300mm * high 890mm

KXJJ series of electron beam impact test machine each model impact range:

1) KXJJ-50 model of the impact energy: 7.5J, 15J (7.5J and 15J for a hammer), 25J, 50J (25J and 50J for a hammer)

Impact energy of KXJJ-5 model: 0.5J, 1J, 2J, 4J, 5J

Return to top

XJJ series mechanical dial type simple beam impact testing machine

XJJ series mechanical dial type simple beam impact testing machine technical parameters:

1) impact speed: 3.8m/s

2) the lifting angle of the pendulum hammer: 150

(3) the corner radius of the impact edge: (2 0.5) mm

4) impact swing moment: pd15=8.03848Nm pd7.5=4.01924Nm

Pd50=26.79492 Nm pd25=13.39746Nm

5) strike center distance: 395mm

(6) the angle of impact cutting edge: (30 1) o

7) jaw fillet radius: (1 0.1) mm

8) the distance between the jaw support line: 62mm

9) dial:

Energy range (J): 0 ~ 7.50 ~ 15 ~ 25 ~ 50

Index value (J): 0.075, 0.150, 0.250, 0.500

10) power supply: 220VAC 50HZ 100VA

11) size: length 550mm * width 300mm * high 890mm

12 required space: before and after 0.4m, the left and right 1.5m, the upper 1.5m

XJJ series mechanical dial type simple beam impact test machine each model impact range:

Impact energy of XJJ-50 model: 7.5J, 15J, 25J, 50J

Impact energy of XJJ-5 model: 0.5J, 1J, 2J, 4J, 5
